Description
|
Operating System |
Android 13+ (frequent updates) |
| Apple CarPlay | Wireless and wired connection (Z-Link) |
| Android Auto |
Wireless and wired connection (Z-Link)
|
|
CHIP |
MLCER01307 |
|
Screen Size |
9 inch |
|
DSP |
32EQ |
|
Brand |
Bosion |
| Model No. | A7240 |
|
Ram |
2/4/8gb |
|
Rom |
32/64/128gb |
| Core | 4 or 8 |
|
Amplifier |
AX7315HX |
|
Radio |
FM and RDS |
|
Wiring |
Plug and play |
|
Connection |
WiFi, USB, Bluetooth |
|
Voltage |
DC 12V |
|
Application |
From Google Play store |
|
General Features |
Bluetooth Phone Link Mirror Screen Split Screen Hi-Res Audio Support Car Steering Wheel Control WiFi GPS Spotify WAZE Apple music Reverse camera Siri Google play store apps Youtube Netflix MP3/4 Player |
|
WIFI |
Built-in |
|
Internet |
WiFi, HotSpot |
|
GPS Maps |
Online & offline maps |
| Package Includes |
1 x Audio system 1 x GPS antenna 1 x Rear camera input cable 1 x RCA cable 2 x USB cable 4 x Screw 1 x Plug and play harness 1 x Facia kit 1 x Optional purchase of an ADH or LED Camera (click here for more info) |
Fits: GOLF & GOLF GTI MK5 2006, 2007, 2008, 2009
NOTE:
Before making a purchase please understand the following:
- We provide a standard VW 36 and 40 PIN main plug and play harness.
- If during installation you find you need a different pin please reach out to us and we will post the new set of plugs to you if we have them.
- If your car has a factory head unit you can find out what pin set is needed on the internet or,
- You can also remove your head unit and count the pins or send us an image of the plugs in the back of the head unit:
- Above we have outlined which cars this unit fits - however the pin offset may be different for some.
If you'd like to send us a photo of the back of your factory radio this will help in confirming compatibility.
Please note: In some VW models, the CANBUS system may require bypassing, which could involve minor cable modifications. Since most VW vehicles don't support aftermarket CANBUS installations, you may need to adjust the wiring slightly. For further details or assistance, please get in touch with us.
For more information please contact us at info@Qualitydins.com.au
